Driveshaft slip yoke for models with A 904 A/T or a 3-speed M/T with 7290 series U-Joints.
Part Number: QW50
Arriving soon!
* Discount Eligible
* Not Eligible For Free Shipping
Driveshaft slip yoke for models with A 904 A/T or a 3-speed M/T with 7290 series U-Joints.
Driveshaft slip yoke-Slip yokes join the tailshaft of the transmission to the driveshaft. One side of the yoke has a splined barrel that slips over the transmission tailshaft, while the other side has ears which attach to the U-joint. This 25-spline yoke measures 6.87". Uses smaller-style 7260-series U-joints.
| U-Joint Series | 7260 | |
| Spline Major Diameter | 1.158 | |
| Spline Count | 25.000 | |
| Spline Type | 25 Based On 26 Spline | |
| Universal Joint Retaining Width | E | 2.625 |
| Universal Joint Bearing Diameter | D | 1.126 |
| Centerline of Joint to End of Spline | J | 6.870 |
| Ground Hub Diameter | R | 1.560 |
| Counterbore Diameter | 0.000 | |
| Counterbore Depth | 0.000 | |
| Style | Snap Ring |
NOTE: All slip yoke measurements are taken from the center of the U-joint cap to the end of the splined barrel. Please measure your original slip yoke before ordering.
